Maven 1 vs Maven 2: Architecture, Lifecycle, and Migration Differences

Maven 2 was a major redesign of Maven 1. This guide focuses on the differences that mattered to build engineers: compatibility, repository configuration, lifecycle behavior, and multi-project execution.

Originally published on 2010-04-14; fully revised and updated.

Maven 1 vs Maven 2 at a glance

According to the original Maven documentation and migration notes, Maven 2 was a complete rewrite of Maven 1 and not backward-compatible with Maven 1 plugins. It also shifted teams toward a stronger POM-and-lifecycle model.

Repository configuration differences

The original post showed two different repository approaches: Maven 1 via properties, and Maven 2 via repository definitions with a legacy layout.

Maven 1 style (project.properties or build.properties)

maven.repo.remote=http://download.java.net/maven/1/,http://www.ibiblio.org/maven/Code language: JavaScript (javascript)

Maven 2 style (pom.xml repository with legacy layout)

<repositories>
  <repository>
    <id>java.net</id>
    <url>http://download.java.net/maven/1</url>
    <layout>legacy</layout>
  </repository>
</repositories>Code language: HTML, XML (xml)

The source also notes that Maven 2 introduced settings.xml for environment-specific and private configuration (such as credentials), while project behavior belongs in pom.xml.

Maven 2 lifecycle workflow

A key change in Maven 2 was the stronger lifecycle model. Running a later phase triggers earlier phases in sequence.

flowchart TD
    A[mvn clean install] --> B[Clean output directory]
    B --> C[Compile source]
    C --> D[Run unit tests]
    D --> E[Package artifact]
    E --> F[Install in local repository]
    F --> G{Run mvn deploy?}
    G -- yes --> H[Publish to remote repository]
    G -- no --> I[Build complete]

• compile: compile source code
• test: run unit tests
• package: create distributable artifact (for example JAR or WAR)
• integration-test: execute integration testing workflow
• install: install artifact in local repository
• deploy: publish artifact to remote repository

# Common Maven 2 era usage
mvn clean install
mvn deploy

# Historical syntax seen in early Maven 2 docs
m2 clean:clean installCode language: PHP (php)

Multi-project support and project layout

The source emphasizes Maven 2’s native multi-project execution with parent descriptors. Invoking a lifecycle from the parent can orchestrate child modules as part of one build.

root/
  pom.xml
  src/
    main/
      java/
        com/daviddewolf/maven/example/App.java
    test/
      java/
        com/daviddewolf/maven/example/TestApp.java

The original article used the following project bootstrap command:

m2 archetype:create -DgroupId=com.daviddewolf.maven -DartifactId=example

Legacy Maven 2 goals frequently referenced

These goals were listed in the original post as commonly useful in Maven 2 workflows.

Migration guidance from Maven 1 to Maven 2

• Inventory all Maven 1 plugins used in CI/CD pipelines.
• Replace Maven 1-specific plugins with Maven 2-compatible equivalents.
• Move project build logic into pom.xml and avoid script-heavy customization patterns.
• Move user/private values (credentials, mirrors, local environment config) into settings.xml.
• If building multiple artifacts, define a parent project and child modules to use native multiproject execution.

Common pitfalls

• Assuming Maven 1 plugins will run in Maven 2 without change.
• Mixing project configuration and private environment settings in the wrong file.
• Following old repository endpoints without validating availability.
• Treating historical commands and goals as current defaults without checking present-day plugin status.

References and original sources

• Maven 1 to Maven 2 information
• Apache Maven home
• Maven model documentation (original link)
• Developer.com reference from original post
• Sonatype Maven book reference from original post
