Working with Kubernetes Cluster using Kubectl Part - 6 - Namespaces

namespace.yaml

apiVersion: v1
kind: Namespace
metadata:
  name: playgroundinyaml

apiVersion: v1

kind: Namespace

metadata:

name: playgroundinyaml

deployment.yaml

apiVersion: apps/v1
kind: Deployment
metadata:
  name: hello-world
  labels:
    app: hello-world
  namespace: playground1
spec:
  replicas: 4
  selector:
    matchLabels:
      app: hello-world
  template:
    metadata:
      labels:
        app: hello-world
    spec:
      containers:
      - name: hello-world
        image: gcr.io/google-samples/hello-app:1.0
        ports:
        - containerPort: 8080

apiVersion: apps/v1

kind: Deployment

metadata:

name: hello-world

labels:

app: hello-world

namespace: playground1

spec:

replicas: 4

selector:

matchLabels:

app: hello-world

template:

metadata:

labels:

app: hello-world

spec:

containers:

- name: hello-world

image: gcr.io/google-samples/hello-app:1.0

ports:

- containerPort: 8080

Commands

ssh aen@c1-master1
cd ~/content/course/m3/demos

#Get a list of all the namespaces in our cluster
kubectl get namespaces

#get a list of all the API resources and if they can be in a namespace
kubectl api-resources --namespaced=true | head
kubectl api-resources --namespaced=false | head

#Namespaces have state, Active and Terminating (when it's deleting)
kubectl describe namespaces

#Describe the details of an indivdual namespace
kubectl describe namespaces kube-system

#Get all the pods in our cluster across all namespaces. Right now, only system pods, no user workload
kubectl get pods --all-namespaces

#Get all the resource across all of our namespaces
kubectl get all --all-namespaces

#Get a list of the pods in the kube-system namespace
kubectl get pods --namespace kube-system

#Imperatively create a namespace
kubectl create namespace playground1

#Imperatively create a namespace...but there's some character restrictions. Lower case and only dashes.
kubectl create namespace Playground1

#Declaratively create a namespace
more namespace.yaml
kubectl apply -f namespace.yaml

#Get a list of all the current namespaces
kubectl get namespaces

#Start a deployment into our playground1 namespace
more deployment.yaml
kubectl apply -f deployment.yaml

#Creating a resource imperitively
kubectl run hello-world-pod \
    --image=gcr.io/google-samples/hello-app:1.0 \
    --generator=run-pod/v1 \
    --namespace playground1

#Where are the pods?
kubectl get pods

#List all the pods on our namespace
kubectl get pods --namespace playground1
kubectl get pods -n playground1

#Get a list of all of the resources in our namespace...Deployment, ReplicaSet and Pods
kubectl get all --namespace=playground1

#Try to delete all the pods in our namespace...this will delete the single pod.
#But the pods under the Deployment controller will be recreated.
kubectl delete pods --all --namespace playground1

#Get a list of all of the *new* pods in our namespace
kubectl get pods -n playground1

#Delete all of the resources in our namespace and the namespace and delete our other created namespace.
#This deletes the Deployment controller, the Pods...or really ALL resources in the namespaces
kubectl delete namespaces playground1
kubectl delete namespaces playgroundinyaml

#List all resources in all namespaces, now our Deployment is gone.
kubectl get all
kubectl get all --all-namespaces

ssh aen@c1-master1

cd ~/content/course/m3/demos

#Get a list of all the namespaces in our cluster

kubectl get namespaces

#get a list of all the API resources and if they can be in a namespace

kubectl api-resources --namespaced=true | head

kubectl api-resources --namespaced=false | head

#Namespaces have state, Active and Terminating (when it's deleting)

kubectl describe namespaces

#Describe the details of an indivdual namespace

kubectl describe namespaces kube-system

#Get all the pods in our cluster across all namespaces. Right now, only system pods, no user workload

kubectl get pods --all-namespaces

#Get all the resource across all of our namespaces

kubectl get all --all-namespaces

#Get a list of the pods in the kube-system namespace

kubectl get pods --namespace kube-system

#Imperatively create a namespace

kubectl create namespace playground1

#Imperatively create a namespace...but there's some character restrictions. Lower case and only dashes.

kubectl create namespace Playground1

#Declaratively create a namespace

more namespace.yaml

kubectl apply -f namespace.yaml

#Get a list of all the current namespaces

kubectl get namespaces

#Start a deployment into our playground1 namespace

more deployment.yaml

kubectl apply -f deployment.yaml

#Creating a resource imperitively

kubectl run hello-world-pod \

--image=gcr.io/google-samples/hello-app:1.0 \

--generator=run-pod/v1 \

--namespace playground1

#Where are the pods?

kubectl get pods

#List all the pods on our namespace

kubectl get pods --namespace playground1

kubectl get pods -n playground1

#Get a list of all of the resources in our namespace...Deployment, ReplicaSet and Pods

kubectl get all --namespace=playground1

#Try to delete all the pods in our namespace...this will delete the single pod.

#But the pods under the Deployment controller will be recreated.

kubectl delete pods --all --namespace playground1

#Get a list of all of the *new* pods in our namespace

kubectl get pods -n playground1

#Delete all of the resources in our namespace and the namespace and delete our other created namespace.

#This deletes the Deployment controller, the Pods...or really ALL resources in the namespaces

kubectl delete namespaces playground1

kubectl delete namespaces playgroundinyaml

#List all resources in all namespaces, now our Deployment is gone.

kubectl get all

kubectl get all --all-namespaces
