Install Jenkins with Docker: Persistent Setup, Port Mapping, and Logs

Running Jenkins in Docker is a practical way to launch a CI server quickly while keeping host setup simple. This guide is for DevOps engineers who want a repeatable Jenkins container setup with persistent data, correct port mapping for UI and agents, and day-2 commands for logs and troubleshooting.

Originally published on 2016-03-10; fully revised and updated.

Prerequisites

• A Linux host with Docker installed and running.
• Access to run Docker commands (root or sudo-enabled user).
• A network path to the host on the port you map for Jenkins UI (for example, 8080 or 49001).
• Disk space for Jenkins home data (plugins, jobs, build history, configuration).

Jenkins-on-Docker workflow

flowchart TD
    A[Install Docker] --> B[Pull Jenkins image]
    B --> C[Prepare persistent data path]
    C --> D[Run Jenkins container with ports and volume]
    D --> E[Open Jenkins web UI]
    E --> F[Get initial admin password]
    F --> G[Complete Jenkins setup wizard]

Step 1: Install Docker on the host

The original article used the following package commands:

apt-get install docker
yum install dockerCode language: JavaScript (javascript)

For additional context, the original post also referenced this Docker installation page: http://www.scmgalaxy.com/scm/software-containers/how-to-install-docker-in-linux.html.

Step 2: Pull a Jenkins image

The original command used docker pull jenkins. In current environments, you will commonly see Jenkins images referenced as jenkins/jenkins with a tag.

docker pull jenkins/jenkins:lts

Step 3: Run Jenkins container

Quick start (no persistent host mapping)

docker run --name jenkins -d -p 8080:8080 -p 50000:50000 jenkins/jenkins:lts

This is fast for testing, but Jenkins data is not safely mapped to a host directory. If the container is removed, your Jenkins state can be lost.

Persistent setup (recommended)

mkdir -p jenkins_home
chown 1000:1000 jenkins_home
docker run --name jenkins -d -p 8080:8080 -p 50000:50000 -v "$PWD/jenkins_home:/var/jenkins_home" jenkins/jenkins:ltsCode language: JavaScript (javascript)

This follows the original post’s core idea: mount /var/jenkins_home to the host so plugins, jobs, and configuration survive container recreation.

Custom host port and root user variant (only if required)

docker run --name jenkins -d -u root -p 49001:8080 -p 50000:50000 -v "$PWD/jenkins_home:/var/jenkins_home" jenkins/jenkins:ltsCode language: JavaScript (javascript)

This keeps the original example of mapping host port 49001 to container port 8080. Use -u root only when permissions force it; default non-root operation is generally safer.

Container options comparison

Get the initial password and check logs

docker exec jenkins cat /var/jenkins_home/secrets/initialAdminPassword
docker logs -f jenkinsCode language: JavaScript (javascript)

The original post showed log access via docker exec name tail -f /var/log/jenkins/jenkins.log. Depending on image layout, that file path may differ; docker logs is usually the most reliable first check.

Access Jenkins in the browser

Open Jenkins at the host and port you mapped, for example:

• http://localhost:8080
• http://localhost:49001 (if you mapped 49001:8080)
• http://<host-ip>:49001 from another machine

Best practices

• Always persist /var/jenkins_home to avoid data loss during container replacement.
• Use the least-privilege runtime user whenever possible; avoid permanent -u root operation.
• Pin an explicit image tag instead of relying on floating defaults.
• Expose port 50000 only if your agent model requires it.
• Document your run command (or move to Docker Compose) so rebuilds are repeatable.
