How to Configure HTTP/HTTPS Proxy on Linux and Windows (CLI, GUI, Registry, and APT)

Originally published on 2016-07-28; fully revised and updated.

If your network requires a proxy server, CLI tools may fail until proxy variables are configured. This guide helps DevOps engineers and administrators set http_proxy/https_proxy on Windows and Linux, make settings persistent, and fix common issues.

This revision is based on the original post: How to Set or Configure Proxy in Linux and Windows System.

When proxy settings are needed

• Your organization routes outbound traffic through a proxy or firewall.
• Commands such as package installs or API calls fail from terminal sessions.
• You need different proxy scopes: current shell, system-wide, or tool-specific (for example, apt).

Proxy setup workflow

Use this flow to choose the right level of configuration and troubleshoot quickly.

flowchart TD
    A[Need outbound internet access] --> B{Operating system}
    B -- Windows --> C[Set proxy in shell or system settings]
    B -- Linux --> D[Export proxy variables]
    C --> E[Test command line access]
    D --> E
    E --> F{Still failing}
    F -- Yes --> G[Configure tool specific proxy such as apt]
    G --> H[If using sudo pass proxy variables]
    F -- No --> I[Done]

Windows vs Linux proxy methods at a glance

Configure proxy on Windows

Temporary settings in Command Prompt

These values apply to the current Command Prompt session.

set http_proxy=http://your_proxy:your_port
set https_proxy=http://your_proxy:your_port
set no_proxy=localhost,127.0.0.1,.example.internal

set http_proxy=http://username:password@your_proxy:your_port
set https_proxy=http://username:password@your_proxy:your_portCode language: JavaScript (javascript)

Set environment variables via GUI

• Open Control Panel and select System.
• Open Advanced system settings, then click Environment Variables.
• Under System variables, click New.
• Add http_proxy and https_proxy with your proxy URL.

Registry and WinHTTP commands

The original post includes registry-based setup and WinHTTP import:

reg add "HKCU\Software\Microsoft\Windows\CurrentVersion\Internet Settings" /v ProxyEnable /t REG_DWORD /d 1 /f
reg add "HKCU\Software\Microsoft\Windows\CurrentVersion\Internet Settings" /v ProxyServer /t REG_SZ /d proxyserveraddress:proxyport /f
netsh winhttp import proxy source=ieCode language: JavaScript (javascript)

Enable, disable, or change proxy quickly

reg add "HKCU\Software\Microsoft\Windows\CurrentVersion\Internet Settings" /v ProxyEnable /t REG_DWORD /d 1 /f
reg add "HKCU\Software\Microsoft\Windows\CurrentVersion\Internet Settings" /v ProxyEnable /t REG_DWORD /d 0 /f
reg add "HKCU\Software\Microsoft\Windows\CurrentVersion\Internet Settings" /v ProxyServer /t REG_SZ /d proxyserveraddress:proxyport /fCode language: JavaScript (javascript)

Legacy credential keys from the original post

The source also listed these keys; validate behavior in your Windows version before relying on them for authentication.

reg add "HKCU\Software\Microsoft\Windows\CurrentVersion\Internet Settings" /v ProxyUser /t REG_SZ /d username
reg add "HKCU\Software\Microsoft\Windows\CurrentVersion\Internet Settings" /v ProxyPass /t REG_SZ /d passwordCode language: JavaScript (javascript)

Configure proxy on Linux

Temporary settings for the current shell

export http_proxy=http://your_proxy:your_port
export https_proxy=http://your_proxy:your_port
export no_proxy=localhost,127.0.0.1,.example.internal

export http_proxy=http://username:password@your_proxy:your_port
export https_proxy=http://username:password@your_proxy:your_portCode language: JavaScript (javascript)

Persist settings in /etc/environment

The original FAQ points to /etc/environment for Ubuntu system-wide proxy values.

http_proxy="http://your_proxy:your_port"
https_proxy="http://your_proxy:your_port"
no_proxy="localhost,127.0.0.1,.example.internal"Code language: JavaScript (javascript)

Configure apt to use a proxy

If apt does not use your shell variables, add explicit proxy lines:

Acquire::http::Proxy "http://10.1.3.1:8080/";
Acquire::https::Proxy "http://10.1.3.1:8080/";Code language: PHP (php)

When sudo does not pass proxy variables

From the original FAQ: a common failure is that sudo does not pass the proxy environment variable by default.

sudo env http_proxy=http://10.1.3.1:8080 apt-get updateCode language: JavaScript (javascript)

FAQ and quick troubleshooting

• If your proxy password contains @, try URL-encoding it as %40.
• If manual export works but apt-get with sudo fails, pass variables explicitly or adjust sudo policy.
• Remember that some tools read environment variables, while others require tool-specific configuration.

echo $http_proxy
echo $https_proxy
echo $no_proxy
env | grep -i proxyCode language: PHP (php)

Common pitfalls and best practices

• Set both http_proxy and https_proxy to avoid inconsistent behavior.
• Avoid storing credentials in plaintext where possible; prefer secure secret handling mechanisms.
• Use URL encoding for special characters in usernames/passwords.
• Document a rollback path (for example, disabling proxy values) for incident response.
• Validate each target tool (curl, apt, build agents) because proxy handling differs by client.
