I was reading article and thought to repost here.
It focuses around Git as the tool for the versioning of all of our source code.
For a thorough discussion on the pros and cons of Git compared to centralized source code control systems, see the web. There are plenty of flame wars going on there. As a developer, I prefer Git above all other tools around today. Git really changed the way developers think of merging and branching. From the classic CVS/Subversion world I came from, merging/branching has always been considered a bit scary (“beware of merge conflicts, they bite you!”) and something you only do every once in a while.
But with Git, these actions are extremely cheap and simple, and they are considered one of the core parts of your daily workflow, really. For example, in CVS/Subversion books, branching and merging is first discussed in the later chapters (for advanced users), while in every Git book, it’s already covered in chapter 3 (basics).
As a consequence of its simplicity and repetitive nature, branching and merging are no longer something to be afraid of. Version control tools are supposed to assist in branching/merging more than anything else.
Enough about the tools, let’s head onto the development model. The model that I’m going to present here is essentially no more than a set of procedures that every team member has to follow in order to come to a managed software development process.
Decentralized but centralized
The repository setup that we use and that works well with this branching model, is that with a central “truth” repo. Note that this repo is only considered to be the central one (since Git is a DVCS, there is no such thing as a central repo at a technical level). We will refer to this repo as
origin, since this name is familiar to all Git users.
Each developer pulls and pushes to origin. But besides the centralized push-pull relationships, each developer may also pull changes from other peers to form sub teams. For example, this might be useful to work together with two or more developers on a big new feature, before pushing the work in progress to
origin prematurely. In the figure above, there are subteams of Alice and Bob, Alice and David, and Clair and David.
Technically, this means nothing more than that Alice has defined a Git remote, named
bob, pointing to Bob’s repository, and vice versa.
The main branches
At the core, the development model is greatly inspired by existing models out there. The central repo holds two main branches with an infinite lifetime:
master branch at
origin should be familiar to every Git user. Parallel to the
master branch, another branch exists called
origin/master to be the main branch where the source code of
HEAD always reflects aproduction-ready state.
origin/develop to be the main branch where the source code of
HEAD always reflects a state with the latest delivered development changes for the next release. Some would call this the “integration branch”. This is where any automatic nightly builds are built from.
When the source code in the
develop branch reaches a stable point and is ready to be released, all of the changes should be merged back into
master somehow and then tagged with a release number. How this is done in detail will be discussed further on.
Therefore, each time when changes are merged back into
master, this is a new production release by definition. We tend to be very strict at this, so that theoretically, we could use a Git hook script to automatically build and roll-out our software to our production servers everytime there was a commit on
Next to the main branches
develop, our development model uses a variety of supporting branches to aid parallel development between team members, ease tracking of features, prepare for production releases and to assist in quickly fixing live production problems. Unlike the main branches, these branches always have a limited life time, since they will be removed eventually.
The different types of branches we may use are:
- Feature branches
- Release branches
- Hotfix branches
Each of these branches have a specific purpose and are bound to strict rules as to which branches may be their originating branch and which branches must be their merge targets. We will walk through them in a minute.
By no means are these branches “special” from a technical perspective. The branch types are categorized by how we use them. They are of course plain old Git branches.
May branch off from:
Must merge back into:
Branch naming convention: anything except
Feature branches (or sometimes called topic branches) are used to develop new features for the upcoming or a distant future release. When starting development of a feature, the target release in which this feature will be incorporated may well be unknown at that point. The essence of a feature branch is that it exists as long as the feature is in development, but will eventually be merged back into
develop(to definitely add the new feature to the upcoming release) or discarded (in case of a disappointing experiment).
Feature branches typically exist in developer repos only, not in
Creating a feature branch
When starting work on a new feature, branch off from the
Incorporating a finished feature on develop
Finished features may be merged into the
develop branch definitely add them to the upcoming release:
--no-ff flag causes the merge to always create a new commit object, even if the merge could be performed with a fast-forward. This avoids losing information about the historical existence of a feature branch and groups together all commits that together added the feature. Compare:
In the latter case, it is impossible to see from the Git history which of the commit objects together have implemented a feature—you would have to manually read all the log messages. Reverting a whole feature (i.e. a group of commits), is a true headache in the latter situation, whereas it is easily done if the
--no-ff flag was used.
Yes, it will create a few more (empty) commit objects, but the gain is much bigger that that cost.
Unfortunately, I have not found a way to make
--no-ff the default behaviour of
git mergeyet, but it really should be.
May branch off from:
Must merge back into:
Branch naming convention:
Release branches support preparation of a new production release. They allow for last-minute dotting of i’s and crossing t’s. Furthermore, they allow for minor bug fixes and preparing meta-data for a release (version number, build dates, etc.). By doing all of this work on a release branch, the
develop branch is cleared to receive features for the next big release.
The key moment to branch off a new release branch from
develop is when develop (almost) reflects the desired state of the new release. At least all features that are targeted for the release-to-be-built must be merged in to
develop at this point in time. All features targeted at future releases may not—they must wait until after the release branch is branched off.
It is exactly at the start of a release branch that the upcoming release gets assigned a version number—not any earlier. Up until that moment, the
develop branch reflected changes for the “next release”, but it is unclear whether that “next release” will eventually become 0.3 or 1.0, until the release branch is started. That decision is made on the start of the release branch and is carried out by the project’s rules on version number bumping.
Creating a release branch
Release branches are created from the
develop branch. For example, say version 1.1.5 is the current production release and we have a big release coming up. The state of
develop is ready for the “next release” and we have decided that this will become version 1.2 (rather than 1.1.6 or 2.0). So we branch off and give the release branch a name reflecting the new version number:
After creating a new branch and switching to it, we bump the version number. Here,
bump-version.sh is a fictional shell script that changes some files in the working copy to reflect the new version. (This can of course be a manual change—the point being that some files change.) Then, the bumped version number is committed.
This new branch may exist there for a while, until the release may be rolled out definitely. During that time, bug fixes may be applied in this branch (rather than on the
developbranch). Adding large new features here is strictly prohibited. They must be merged into
develop, and therefore, wait for the next big release.
Finishing a release branch
When the state of the release branch is ready to become a real release, some actions need to be carried out. First, the release branch is merged into
master (since every commit on
master is a new release by definition, remember). Next, that commit on
master must be tagged for easy future reference to this historical version. Finally, the changes made on the release branch need to be merged back into
develop, so that future releases also contain these bug fixes.
The first two steps in Git:
The release is now done, and tagged for future reference.
To keep the changes made in the release branch, we need to merge those back into
develop, though. In Git:
This step may well lead to a merge conflict (probably even, since we have changed the version number). If so, fix it and commit.
Now we are really done and the release branch may be removed, since we don’t need it anymore:
May branch off from:
Must merge back into:
Branch naming convention:
Hotfix branches are very much like release branches in that they are also meant to prepare for a new production release, albeit unplanned. They arise from the necessity to act immediately upon an undesired state of a live production version. When a critical bug in a production version must be resolved immediately, a hotfix branch may be branched off from the corresponding tag on the master branch that marks the production version.
The essence is that work of team members (on the
develop branch) can continue, while another person is preparing a quick production fix.
Creating the hotfix branch
Hotfix branches are created from the
master branch. For example, say version 1.2 is the current production release running live and causing troubles due to a severe bug. But changes on
develop are yet unstable. We may then branch off a hotfix branch and start fixing the problem:
Don’t forget to bump the version number after branching off!
Then, fix the bug and commit the fix in one or more separate commits.
Finishing a hotfix branch
When finished, the bugfix needs to be merged back into
master, but also needs to be merged back into
develop, in order to safeguard that the bugfix is included in the next release as well. This is completely similar to how release branches are finished.
master and tag the release.
Next, include the bugfix in
The one exception to the rule here is that, when a release branch currently exists, the hotfix changes need to be merged into that release branch, instead of
develop. Back-merging the bugfix into the release branch will eventually result in the bugfix being merged into
develop too, when the release branch is finished. (If work in
develop immediately requires this bugfix and cannot wait for the release branch to be finished, you may safely merge the bugfix into
develop now already as well.)
Finally, remove the temporary branch:
While there is nothing really shocking new to this branching model, the “big picture” figure that this post began with has turned out to be tremendously useful in our projects. It forms an elegant mental model that is easy to comprehend and allows team members to develop a shared understanding of the branching and releasing processes.
A high-quality PDF version of the figure is provided here. Go ahead and hang it on the wall for quick reference at any time.
